OCEAN SIGNAL SAFESEA S100 SART, P/N: 710S-00607
- Product Code: S100
- Product SKU:
- Item Code: GMDS-OSN-S100 -
- Availability: In Stock
SafeSea S100 Radar SART
The Ocean Signal SafeSea S100 Radar Search and Rescue Transponder or Radar SART is a critical component of maritime safety equipment, designed to enhance visibility and aid in search and rescue operations. With its advanced radar reflector technology, this beacon ensures your vessel is easily detectable even in adverse weather conditions and low visibility situations. Compact and durable, the S100 Radar SART is easy to deploy and highly reliable, offering peace of mind for sailors and boaters alike. Whether navigating busy shipping lanes or sailing in remote waters, the Ocean Signal SafeSea S100 Radar SART is an essential addition to any vessel’s safety gear, ensuring swift and effective response in emergency situations.
The SeaSafe S100 SART is designed to assist in the rescue and recovery of liferafts and survival craft. When switched on, the SART remains in a standby mode until automatically activated by an X Band Radar sweep from any vessel in the vicinity. The SafeSea S100 transmits a series of pulses which are displayed on the ship’s Radar as a line of dots, providing a bearing to the survival craft.
SKU: 710S-00607
The SafeSea S100 Search and Rescue Transponder (Radar SART) is a dedicated radar transponder that complies with IMO SOLAS regulations.
Carriage requirements
Frequency range
9.2-9.5GHz
Radiated output power
>26dBm eirp
Frequency range
9.2-9.5GHz
Radiated output power
>26dBm eirp
Operational Life
>96hours standby plus >12hours operational
Battery Replacement Interval
5years
Operational Life
>96hours standby plus >12hours operational
Battery Replacement Interval
5years
Operating Temperature Range
-20°C to +55°C
Storage Temperature Range
-30°C to +70°C
Waterproof
>10metres at +20°C
Operating Temperature Range
-20°C to +55°C
Storage Temperature Range
-30°C to +70°C
Waterproof
>10metres at +20°C
Height
227mm
Body Diameter (max)
65mm (82mm)
Height
227mm
Body Diameter (max)
65mm (82mm)
IMO regulations
A.694(17); MSC.247(83)
International Standards Radio
IEC61097-1
International Standards EMC
IEC60945
European approval
Marine Equipment Directive A.1/4.18
USA Standards
FCC CFR47 part 80.1101
IMO regulations
A.694(17); MSC.247(83)
International Standards Radio
IEC61097-1
International Standards EMC
IEC60945
European approval
Marine Equipment Directive A.1/4.18
USA Standards
FCC CFR47 part 80.1101
UK Module D Certificate
S100 EU Declaration of Conformity (MED)
S100 EU Type Examination Certificate (MED)
S100 UK Declaration of Conformity (MER)
S100 UK Type Examination Certificate (MER)
S100 US Equipment Authorization Certificate (FCC)
S100 Canadian Certificate (ISED)
S100 China Approval Certificate (CCS)
LB3S Battery – Safety Data Sheet
The SafeSea S100 Search and Rescue Transponder (SART) is a dedicated radar transponder that complies with IMO SOLAS regulations.
- Superior battery life – even at -20°C
- User-replaceable battery
- Non Hazardous battery
- Five-year replacement interval
- Compact size for easy liferaft packing
- Supplied complete with telescopic pole and storage bracket
Carriage requirements
- SARTs are required on all IMO SOLAS vessels on international voyages:-
- One on 300-500GRT
- Two if over 500GRT
- One SART per every four liferafts on ro-ro passenger vessels
- Nationally mandated vessels, including fishing vessels, passenger craft, commercial workboats, etc
- Most Super and Mega yachts are required to carry a SART, especially if covered by the MCA code of practice, which is recognized by many countries.
- Voluntary fit vessels will also benefit by carrying a SART
The SeaSafe S100 SART is designed to assist in the rescue and recovery of liferafts and survival craft. When switched on, the SART remains in a standby mode until automatically activated by an X Band Radar sweep from any vessel in the vicinity. The SafeSea S100 transmits a series of pulses which are displayed on the ship’s Radar as a line of dots, providing a bearing to the survival craft.
The activation controls are identical to those on theSafeSea E100 EPIRB, making use by unskilled operators much easier
Carriage requirements
- SARTs are required on all IMO SOLAS vessels on international voyages:-
- One on 300-500GRT
- Two if over 500GRT
- One SART per every four liferafts on ro-ro passenger vessels
- Nationally mandated vessels, including fishing vessels, passenger craft, commercial workboats, etc
- Most Super and Mega yachts are required to carry a SART, especially if covered by the MCA code of practice, which is recognised by many countries.
- Voluntary fit vessels will also benefit by carrying a SART
What is a SART
A search and rescue transponder is a self-contained, waterproof transponder intended for emergency use at sea. These devices may be either a radar-SART, or a GPS-based AIS-SART. The radar-SART is used to locate a survival craft or distressed vessel by creating a series of dots on a rescuing ship's radar display.
MER UK Approved ‘Red Ensign’ marked marine equipment.
